451-10-204-00-003101
Straight interconnect pin connector 2.54 mm, solder tail, double row
Part number
451-10-204-00-003101
Description
Straight interconnect pin connector 2.54 mm, solder tail, double row, 4 contacts, 0,25 µm Gold / 0,25 µm Gold, L1 = 6.2 mm
Technical Documents
Number of Contacts
PP Plating Code
| L1 (mm) | L2 (mm) | XXX Code |
|---|---|---|
| 6.2 | 4.7 | 003 |
| 8.4 | 3.5 | 004 |
| 15.3 | 3.5 | 005 |
| 21.2 | 3.5 | 016 |
| 27.4 | 3.5 | 017 |
